Hi-Rib

  • Economical medium profile roofing or siding panel
  • Applies over open framing or solid substrate
  • 36" Panel coverage
  • Trapezoidal ribs 7" on center
  • 1 1/4" Bell top trapezoidal rib height
  • Recommended minimum roof slope 3/12 pitch
  • Anti-siphoning side lap
  • Residential, light commercial and agricultural uses
  • Class A fire resistance
  • Class 4 hail impact resistance
  • Available in Galvanized, Galvalume and Painted
  • 24, 22,20 and 18 gauge thickness available

      Color Chart

      Hi-Rib panel Specification Sheet  (pdf. format) 48.4 kb.





 Chambers Steel Service     1800 Broadway Avenue     West Middlesex, Pennsylvania 16159

Tel: 1-724-981-3313    Fax: 1-724-981-3757    Toll Free 1-800-352-3313
